Traffic on dab175-dmz <-> vpn (outside)
| System: | vpn in Jones 100 |
| Maintainer: | noc@memphis.edu |
| Description: | Ethernet1/13 (outside) |
| ifType: | ethernetCsmacd (6) |
| ifName: | Ethernet1/13 |
| Max Speed: | 1 GBits/s |
The statistics were last updated Friday, 6 February 2026 at 0:10,
at which time 'jo100-vpn-duo-fw1.memphis.edu' had been up for 133 days, 7:22:04.
`Daily' Graph (5 Minute Average)
|
Max |
Average |
Current |
| In |
19.2 kb/s (0.0%) |
12.2 kb/s (0.0%) |
1280.0 b/s (0.0%) |
| Out |
75.9 kb/s (0.0%) |
56.3 kb/s (0.0%) |
4432.0 b/s (0.0%) |
`Weekly' Graph (30 Minute Average)
|
Max |
Average |
Current |
| In |
14.4 kb/s (0.0%) |
3872.0 b/s (0.0%) |
4960.0 b/s (0.0%) |
| Out |
66.9 kb/s (0.0%) |
16.5 kb/s (0.0%) |
21.6 kb/s (0.0%) |
`Monthly' Graph (2 Hour Average)
|
Max |
Average |
Current |
| In |
100.9 kb/s (0.0%) |
2912.0 b/s (0.0%) |
12.6 kb/s (0.0%) |
| Out |
368.3 kb/s (0.0%) |
14.9 kb/s (0.0%) |
58.4 kb/s (0.0%) |
`Yearly' Graph (1 Day Average)
|
Max |
Average |
Current |
| In |
35.5 kb/s (0.0%) |
1328.0 b/s (0.0%) |
12.5 kb/s (0.0%) |
| Out |
359.5 kb/s (0.0%) |
7656.0 b/s (0.0%) |
57.6 kb/s (0.0%) |
| GREEN ### |
Incoming Traffic in Bits per Second |
| BLUE ### |
Outgoing Traffic in Bits per Second |
