Traffic on jo100-dmz-s1 <-> jo100-multi-fw1 Link
| System: | jo100-dmz-s1 in jo100 |
| Maintainer: | noc@memphis.edu |
| Description: | Eth2/25 |
| ifType: | ethernetCsmacd (6) |
| ifName: | Eth2/25 |
| Max Speed: | 10 GBits/s |
The statistics were last updated Thursday, 18 September 2025 at 4:10,
at which time 'jo100-dmz-s1' had been up for 15 days, 1:08:28.
`Daily' Graph (5 Minute Average)
|
Max |
Average |
Current |
| In |
1188.8 Mb/s (11.9%) |
558.2 Mb/s (5.6%) |
323.1 Mb/s (3.2%) |
| Out |
7026.9 Mb/s (70.3%) |
3244.7 Mb/s (32.4%) |
1817.3 Mb/s (18.2%) |
`Weekly' Graph (30 Minute Average)
|
Max |
Average |
Current |
| In |
1109.7 Mb/s (11.1%) |
512.2 Mb/s (5.1%) |
408.8 Mb/s (4.1%) |
| Out |
6838.7 Mb/s (68.4%) |
2967.4 Mb/s (29.7%) |
1573.7 Mb/s (15.7%) |
`Monthly' Graph (2 Hour Average)
|
Max |
Average |
Current |
| In |
2056.5 Mb/s (20.6%) |
449.4 Mb/s (4.5%) |
470.1 Mb/s (4.7%) |
| Out |
6572.1 Mb/s (65.7%) |
2499.4 Mb/s (25.0%) |
2215.0 Mb/s (22.2%) |
`Yearly' Graph (1 Day Average)
|
Max |
Average |
Current |
| In |
683.0 Mb/s (6.8%) |
340.7 Mb/s (3.4%) |
595.7 Mb/s (6.0%) |
| Out |
4287.5 Mb/s (42.9%) |
1989.3 Mb/s (19.9%) |
3567.1 Mb/s (35.7%) |
| GREEN ### |
Incoming Traffic in Bits per Second |
| BLUE ### |
Outgoing Traffic in Bits per Second |
