Active TCP UDP Sessions on PA-5060-Jones-Hall
| System: | pa.memphis.edu |
| Maintainer: | noc@memphis.edu |
The statistics were last updated Thursday, 18 September 2025 at 4:10,
at which time 'PA-5260-Jones-Hall' had been up for 61 days, 19:16:46.
`Daily' Graph (5 Minute Average)
|
Max |
Average |
Current |
| Active TCP Sessions |
276.8 kSessions (6.6%) |
129.5 kSessions (3.1%) |
69.6 kSessions (1.7%) |
| Active UDP Sessions |
363.2 kSessions (8.7%) |
135.2 kSessions (3.2%) |
54.6 kSessions (1.3%) |
`Weekly' Graph (30 Minute Average)
|
Max |
Average |
Current |
| Active TCP Sessions |
320.0 kSessions (7.6%) |
121.1 kSessions (2.9%) |
69.6 kSessions (1.7%) |
| Active UDP Sessions |
442.7 kSessions (10.6%) |
127.5 kSessions (3.0%) |
53.3 kSessions (1.3%) |
`Monthly' Graph (2 Hour Average)
|
Max |
Average |
Current |
| Active TCP Sessions |
329.9 kSessions (7.9%) |
107.0 kSessions (2.6%) |
86.8 kSessions (2.1%) |
| Active UDP Sessions |
455.7 kSessions (10.9%) |
105.4 kSessions (2.5%) |
78.0 kSessions (1.9%) |
`Yearly' Graph (1 Day Average)
|
Max |
Average |
Current |
| Active TCP Sessions |
329.9 kSessions (7.9%) |
90.5 kSessions (2.2%) |
149.6 kSessions (3.6%) |
| Active UDP Sessions |
552.1 kSessions (13.2%) |
79.7 kSessions (1.9%) |
164.3 kSessions (3.9%) |
| GREEN ### |
Active TCP Sessions |
| BLUE ### |
Active UDP Sessions |
| DARK GREEN ### |
Maximal 5 Minute Incoming Traffic |
| MAGENTA ### |
Maximal 5 Minute Outgoing Traffic |
